Sun Fire[tm] V880 Server

V880
Sun V880

Processors | Main Memory | Standard Interfaces | Internal Mass Storage | Power Supplies
Environment | Regulations | Dimensions and Weight | Clearance and Service Access | Rack Mounting

Processors
top

Number: Up to eight

Architecture: ,
X7047A - 750 MHZ UltraSPARC [tm]III (64-bit)
X7028A - 900 MHz UltraSPARC III (64 bit)
X7268A - 1050 MHZ UltraSPARCIII (64 bit) X6895A - 1200 MHz UltraSPARC III (64 bit)

Memory Management: MMU with 64 I TLB entries and 64 D-TLB entries, 8192 hardware supported contexts

Cache Memory: 64-KB data and 32-KB instruction on chip per processor

Secondary: 8MB external per processor

501-5142 - V880 I/O board
501-4300 - V880 Motherboard
501-6323 - V880 Motherboard

Main Memory
top

Capacities: Total of 16 DIMM memory slots available per CPU/Memory board

128, 256, 512MB, or 1GB*(16GB maximum per CPU/Memory board, 64GB maximum when configured with 8 processors)

*1GB DIMMs are not supported on 750 MHz CPU/Memory boards.

Note: Install DIMMs in groups of four. 1050 MHZ CPU/memory boards require that all memory DIMM slots be fully populated.

Memory Type: 232-Pin 7-nS memory modules
X7051A - 2GB Memory kit (4 x 512MB SDRAM DIMMs)
 X7050A - 512MB Memory kit (4 x 128MB SDRAM DIMMs)
X7053A - 1GB Memory kit (4 x 256MB SDRAM DIMMs)
X7056A - 4 GB Memory Kit(4 × 1GB SDRAM DIMMs)

Standard Interfaces
top

Ethernet:

  • One Gigabit ether (1000 Base-SX) dual SC fiber optic port
  • One ether/fast ether (10 Base-T/100 Base- T)twisted pair standard connector (RJ-45)

X4444A - Quad GigaSwift Ethernet UTP (QGE)
X1033A - Sun FastEthernet PCI Adapter (FE/P) 2.0
X1034A - Quad FastEthernet PCI (QFE/P)
X1141A - Gigabit Ethernet PCI (GBE/P) 2.0
X1150A - Sun GigaSwift Ethernet UTP (Copper)
X1151A - Sun GigaSwift Ethernet MMF (Fiber)
X3150A - Sun GigaSwift Ethernet UTP (Copper)
X3151A - Sun GigaSwift Ethernet MMF (Fiber)
X4150A - GigaSwift Ethernet UTP (GCS)
X4151A - GigaSwift Ethernet MMF (GFS)
X4445A - Quad GigaSwift PCI-X Ethernet (QGE-X)
X5558A - XFP Optical Transceiver Multi Mode Fibre
X5559A - XFP Optical Transceiver Single Mode Fibre

Keyboard and mouse: USB (uses one of the two standard USB (Type A) port

PCI: Nine full sized, hot swap, PCI slots pliant with specification Revision 2.1:

  • Two slots operating at 66MHz, 64 or 32 bits wide, 3.3 volts

Seven slot operating at 33 MHz, 64 or 32 bits wide, 5 volts

Remote System Controller: One RSc card plugs into a dedicated slot on the system I/O board which includes integrated modem, serial and Ether interfaces.

  • One 56 Kbps modem port (RJ-11)
  • One EIA-232D serial port (RJ-45)
  • One 10 Mbps Ether port (RJ-45)

Serial: Two RS-232D/RS-423 serialports (DB25) via splitter cable (x985A)

USB: Two standard Universal Serial Bus (USB) Type A connectors

SG-XPCI1FC-EM2 - 2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI1FC-QF4 - 4Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI1FC-QL2 - 2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI2FC-EM2 - Sun Microsystems PCI-X Dual Channel 2GB/sec
SG-XPCI2FC-QF2-Z - Sun Microsystems PCI - 2GB Dual FC Host Adapter (RoHS).
SG-XPCI2FC-QF4 - 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
X6727A - Sun Microsystems PCI - Dual FC Network adapter +
SG-XPCI1FC-JF2 - Sun Microsystems PCI - 2GB Single FC Host Adapter.
SG-XPCI1FC-QF2 - Sun Microsystems PCI - 2GB Single FC Host Adapter.
SG-XPCI2FC-JF2 - Sun Microsystems PCI - 2GB Dual FC Host Adapter.
SG-XPCI2FC-QF2 - Sun Microsystems PCI - 2GB Dual FC Host Adapter.
X6767A - Sun Microsystems PCI - 2GB Single channel Fiber Channel Host Bus Adapter. (FC HBA)
X6768A - Sun Microsystems PCI - 2GB /sec. Dual Channel Fiber Channel Host Bus Adapter. (FC HBA)
X6799A - Sun Microsystems PCI - Single FC Network Adapter 100MB/s with optical interface



Internal Mass Storage
top

Host adapters: Internal SCSI to support the internal DVD and optional removable media devices.

Up to nine PCI-to-dual FC-AL adapters or PCi-to-UltraSCSI adapters

Disks: Up to 12 3.5"x1" 10000 RPM FC-AL disks, 36.4GB, and 146GB capacity. Maximum total capacity of 1.7TB
X6742A - 73.4GB FC-AL 10000 RPM
X6805A - 73.4GB FC-AL 10000 RPM
XRA-FC1CB-146G10K - 146GB 10000 RPM FC-AL
X6724A - 36.4GB FC-AL 10000 RPM

DVD-ROM: 10X DVD-ROM (standard)
X6168A

Tape: Optional 12GB DDS 3 4mm or 20 GB DDS4 4mm single drive.
SG-XTAPDAT72-5F68 - DAT 72 Tape Drive
X6283A - 12 - 24GB 4MM
X6295A - 20 - 40GB 4MM
Power Supplies
top

300-1353 - Power Supply for V880
Type: 2 minimum, 3 for N+1 redundancy, individual power cords

Output: 1100W maximum per power supply
Enviornment
top

AC input: 100-240 VAC, 47-63 Hz, 15 A(max) per power cord, 1.48 KVA per power supply(3.0 KVA)

Input power: 3000W

Heat Output: see doc 48584 for details

Temperature: Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -20° C to 60° C (-4° F to 140° F)

Altitude: Operating: 3000 m (10,000 ft.)
Nonoperating: 12,000 m (40,000 ft.)

Acoustic noise: Operating: 6.7 bels

Idling 7.6 bels

Vibration: Operating: 0.0002 G 2 /Hz, 5 - 500 Hz (random) (deskside)
0.00015 G 2 /Hz, 5 - 500 Hz (random) (rackmounted)
Nonoperating: 0.002 G 2 /Hz, 5 - 500 Hz (random) (deskside)
0.0015 G 2 /Hz, 5 - 500 Hz (random) (rackmounted)

Shock: Operating: 4 G peak, 11 milliseconds half-sine pulse (deskside)
3 G peak, 11 milliseconds half-sine pulse (rackmounted)
Nonoperating: 15 G peak, 11 milliseconds half-sine pulse (deskside)
10 G peak, 11 milliseconds half-sine pulse (rackmounted)

Number of cords: 3

Plug Type-U.S.: NEMA 5-15P

Plug type International: IEC 320, 10 A

300-1353 - Power Supply
375-0071 - Power Distribution Board

Regulations :(meets or exceeds the following requirements)
top

Safety: UL 60950, CSA C22.2, EN 60950 (from UL), TUV 60950, UL CB Scheme IEC 950 (CE Mark), GOST

RFI/EMI: Class A:Australia/New Zealand AS/NZ 3548, Industry Canada ICES-003,European munity EN55022/CISPR22,Japan VCCI,Taiwan CNS 13438,and US FCC 47CFR15.B

Immunity: EN55024,i.e.EN61000-4-2,EN61000-4-3, EN61000-4-4,EN61000-4-5,EN61000-4-6, EN61000-4-8,and EN61000-4-11

X-ray: US DHHS 21 CFR Subchapter J, PTB German X-ray Decree

Dimensions and Weights
top

Height : 71.4 cm (28.1 in.) with castors

Width: 48.0 cm (18.9 in.)

Depth: 83.6 cm (32.9 in.)

Weight: 88.1 kg (194.0 lb.)(minimum, approximate)
130.9 kg (288.0 lb.)(maximum, approximate)

Power Cord: 2.5 m (8.2 ft.)

Clearance and Service Access
top

Front: Deskside - 91 cm (36 in.)
Rackmount - 122 cm (48 in.)

Rear: 91 cm (36 in.)

Right: 91 cm (36 in.)

Left: 91 cm (36 in.)

Rack mounting
top 		Fits into Sun StorEdge 72" Expansion Rack, Sun Fire Cabi, Sun Rack 900, & standard mercial 19-inch wide, 36-inch deep racks, but in third party racks, the front and rear doors must be at least 63% open area for the Sun Fire V880 to cool properly. To facilitate rack mounting, heavier ponents such as power supplies may be removed.
A30-WUF8-16GRF : A30-WRF8-16GRF : A30-WRF4-08GRF : A30-WTF4-08GRF : A30-WTF2-04GRF : A30-WTF8-16GRF : A30-WRF2-04GRF : A30-WSF2-04GRF : A30-WSF4-08GRF : A30-WSF8-16GRF : A30-WUF2-04GRF : A30-WUF4-08GRF : A30-WSF4-16GRF : A30-WSF4-32GRF : A30-WUF4-16GRF : A30-WUF4-32GRF : A30-WUF8-32GRF : A30-WUF8-64GRF :
